Duratuf Premium Electrical Rubber Mat in Mexico for High-Voltage Safety
Mexico’s electrical safety standards are governed by NOM (Normas Oficiales Mexicanas), developed in alignment with IEC standards through ANCE (Asociación Nacional de Normalización y Certificación del Sector Eléctrico). CFE (Comisión Federal de Electricidad) manages the national generation, transmission, and distribution network across 16 regional distribution units, with CRE (Comisión Reguladora de Energía) as the independent regulatory body. Mexico’s medium voltage network ( defined as 1,000V to 34.5kV ) is the primary operating range for CFE distribution substation work, where IEC 61111:2009 is the applicable insulating mat standard under the NOM framework. For industrial facilities operating under US or European parent company specifications, ASTM D178 is the standard most commonly specified.
Mexico is the world’s seventh largest automobile manufacturer, with major OEM facilities from General Motors, Ford, Volkswagen, Audi, BMW, Toyota, and Nissan concentrated in the Bajío region, Puebla, and northern industrial corridors. PEMEX operates six refineries and extensive upstream infrastructure in Campeche, Tabasco, and Veracruz, each with large electrical maintenance requirements. Mexico’s nearshoring boom is bringing new electronics, semiconductor supply chain, and advanced manufacturing facilities into Monterrey, Guadalajara, and the Bajío, all requiring certified electrical safety mats as part of their EHS and operational setup.
Duratuf electrical insulating mats are type-tested to ASTM D178 and IEC 61111:2009 across Class 0 to Class 4, covering working voltages from 1.0 kV to 36.0 kV. ASTM D178 Type I mats are the standard supply for most Mexican industrial specifications. ASTM D178 Type II mats, with additional ozone, flame, or oil resistance, are available for PEMEX refinery and petrochemical facility specifications. IEC 61111:2009 mats are supplied for CFE utility projects and NOM-governed installations. Both ranges perform reliably across Mexico’s varied climate zones, from the extreme heat of Sonora and Baja California to the highland temperatures of the Bajío and Mexico City regions.
Certifications & Memberships
Technical Specification of Electrical Insulating Mats
ASTM D178 Insulating Mat Specifications
| Product Code | Class | Max Use Voltage | AC Proof Voltage | Withstand Voltage | Recom. Thickness |
|---|---|---|---|---|---|
| IM-IEC-C0 | 0 | 1.0 kV | 5.0 kV | 10.0 kV | 2.0 mm |
| IM-IEC-C1 | 1 | 7.5 kV | 10.0 kV | 20.0 kV | 2.0 mm |
| IM-IEC-C2 | 2 | 17.0 kV | 20.0 kV | 30.0 kV | 3.0 mm |
| IM-IEC-C3 | 3 | 26.5 kV | 30.0 kV | 40.0 kV | 4.0 mm |
| IM-IEC-C4 | 4 | 36.0 kV | 40.0 kV | 50.0 kV | 5.0 mm |
Customisation available: thickness up to 14 mm, width up to 1,220 mm, length up to 15 m. Contact us for cut-to-size orders.
IEC 61111:2009 Electrical Mat Specifications
| Product Code | Class | Max Use Voltage | AC Proof Voltage | Dielectric Voltage | Recom. Thickness |
|---|---|---|---|---|---|
| IM-ASTM-C0 | 0 | 1.0 kV | 5.0 kV | 10.0 kV | 3.2 mm |
| IM-ASTM-C1 | 1 | 7.5 kV | 10.0 kV | 20.0 kV | 4.8 mm |
| IM-ASTM-C2 | 2 | 17.0 kV | 20.0 kV | 30.0 kV | 6.4 mm |
| IM-ASTM-C3 | 3 | 26.5 kV | 30.0 kV | 40.0 kV | 9.5 mm |
| IM-ASTM-C4 | 4 | 36.0 kV | 40.0 kV | 50.0 kV | 12.7 mm |
Unless specified, ASTM D178 mats are supplied as Type I. Type II variants with ozone, flame, or oil resistance are available on request.
Applications of Electrical Rubber Mats in Mexico
Electrical insulating mats are required wherever operators work near live equipment at system voltage, from CFE substations to automotive plant utility rooms to PEMEX refinery control areas. Duratuf mats are used across the following installation types in Mexico:
- CFE distribution substations operating at 13.8kV, 23kV, and 34.5kV across 16 regional distribution units nationwide
- PEMEX refinery electrical control rooms and switchgear areas at Tula, Cadereyta, Salamanca, Salina Cruz, and the Dos Bocas refinery in Tabasco
- PEMEX upstream platform support base and onshore facility electrical maintenance areas in Campeche and Veracruz
- Automotive manufacturing plant HT/LT control rooms and electrical utility infrastructure at Bajío corridor facilities.
- Maquiladora and electronics manufacturing electrical panels in Tijuana, Ciudad Juárez, and Monterrey industrial parks
- Nearshoring industrial park electrical infrastructure across Nuevo León, Jalisco, Querétaro, and Guanajuato
- Aerospace manufacturing facility electrical control rooms in Querétaro Aerospace Park and Mexicali
- CEMEX, Cruz Azul, and Holcim cement plant HT/LT panels and switchgear rooms across production facilities
- Mining operation electrical maintenance areas in Zacatecas, Sonora, and Chihuahua.
Features of IEC 61111:2009 Electrical Insulating Mats | Duratuf
Exclusive Features Of Duratuf Electrical Insulation Mats
High Di-electric Strength
Quality-Certified
Safety-Audit Passed
Chemical, UV, Ozone and Flame Retardant
Moisture and Water Resistant
Up to 10,000 sq m Ready Stock
Free Expert Guidance
Competitive Pricing
End-to-End Customer Support
